Hydrofarm PHANTOM CMH - Electrical Specifications; Ballast LED Status Indicators

BALLAST LED STATUS INDICATORS
STATUS LED (LAMP 1/LAMP 2)
Ballast Locked Flash X 1
Output Error Flash X 2
Low Input Voltage Flash X 3
Over Temperature Flash X 4
High Input Voltage Flash X 5
PHBMH6010  BALLAST SPECIFICATIONS
Watts
Main
Voltage
Operating
Voltage
Range
Max Input
Power
Output Power Settings
Power
Factor
Ignitor
Voltage
OCV THD CF ta tc
315W
(x2)
120-240V 110-265V 764W(382W x2) 60%-85%-100%-105% ≥ 0.97 3-5 kV 250V < 8% 1.414-1.6 40°C/104°F 80°C/176°F
PHBMH6010  BALLAST INPUT AMPERAGE
Imax 120/240V SUPER(105%) 120/240V 100% 120/240V 85% 120/240V 60% 120/240V
6.6A(3.3x2)/3.0A(1.5x2) 6.2A(3.1 x2)/3.0A(1.5 x2) 5.8A(2.9 x2)/3.0A(1.5 x2) 5.0A(2.5 x2)/2.4A(1.2 x2) 3.4A(1.7 x2)/1.8A(0.9 x2)
x2 - Amperage for single lamp use
ELECTRICAL SPECIFICATIONS
