RED:
Pump 1 / 2-Speed
BROWN:
Pump 2 / 2-Speed
PINK:
Pump 1 or 2 / 1-Speed
PURPLE:
Air Blower / 1-Speed
YELLOW:
Ozone
BLUE:
Circ. Pump
WHITE:
12V Light or Fireman's Switch
LIGHT PURPLE:
Switched Acc. or Versi-Heat (Solid-State)
ORANGE:
Fiber Optic or Versi-Heat (Mechanical)
GREEN:
Hot Auxiliary Circuit or 120V Light
RECEPTACLE GUIDE
To make things easy, we have developed our own unique set of color-coded
cords & receptacles. Use the chart below when connecting components.
