ELECTRICAL REQUIREMENTS
The GFCI (Ground Fault Circuit Interrupter) is a mandatory electrical safety device required for all
hydromassage bathtubs as specified in the National Electrical Code Article 680-70.
Use copper conductors ONLY. The ground must be sized following the National Electric Code, Table 250-122.
DEDICATED CIRCUIT INSTALLATION
A qualified and licensed electrician in accordance with the National Electric Code (NEC) Article 680, Canadian
Electric Code, and with any local codes must accomplish the electrical installation.
Your bath equipment may require a DEDICATED CIRCUIT. This means no other appliances or lights can be
on this circuit. Refer to equipment data label for power supply requirements of your bath heater.
For Power conductor size, refer to the National Electric Code Table 310-16.
All connections must be made according to the electrical installation label on the outside of the control box.
Follow the instructions from the label if they are different than the instructions in this manual. If your electrician
is not absolutely sure how to connect your system correctly, call your local dealer. Any mistake may be costly and
void your equipment warranty.
TR200X-65
TR200X-10
TR220X-20*
TR200X-15
6
9
9
13
15
15
15
15
YES
YES
YES
YES
YES
YES
YES
YES
MODELS
MAX
AMPS
CIRCUIT
BREAKER
GFCI
REQUIRED
BONDING
REQUIRED
CIRCUIT INSTALLATION
Ÿ Refer to chart below
If your system
amps are...
6A
9A
13A
THEN
THEN
THEN
You can use a circuit
this size...
15A/120V
15A/120V or 240V
15A/120V
NOTE: Read both the sections below to determine the electrical requirements of your
system before proceeding.
SYSTEM POWER REQUIREMENTS
* = 240V SYSTEM
5
