Hydrotek H-8000C Series User Manual

Hydrotek Autoush Valves
8000 Series
Meets A.S.S.E. Standard 1037-89
H-8000C (AC Powered) HB-8000C (Baery Powered)
HYDROTEK INTERNATIONAL, INC.
5055 Forsyth Commerce Rd., Ste 124
Orlando, FL 32807
800.922.9883 (Phone)
866.670.5580 (Fax)
www.hydrotekintl.com
The 8000 Series Flush Valves are available in:
H-8000C Series (AC Powered):
9 H-8000C-A (Closet)
9 H-8000C-B1 (Urinal)
9 H-8000C-B2 (Urinal)
*Water conservaon, concealed and AC with DC
backup models available*
HB-8000C Series (Baery Powered):
9 HB-8000C-A (Closet)
9 HB-8000C-B1 (Urinal)
9 HB-8000C-B2 (Urinal)
*Water conservaon and concealed models available*
HB-8000SLE Series (Solar Powered):
9 HB-8000SLE-A (Closet)
9 HB-8000SLE-B1 (Urinal)
9 HB-8000SLE-B2 (Urinal)
*Water conservaon and retrot models available*
HB8RFKC Series Retrot Models (Baery Powered):
Sloan & Zurn Retrot
9 HB8RFKC-C (Closet)
9 HB8RFKC-U (Urinal)
Delany Retrot
9 HB8RFKC-CD (Closet)
9 HB8RFKC-UD (Urinal)
*Water conservaon models available*
PLUMBING SPECIFICATIONS:
Model Fixture Supply Line Top Spud Flow Rate
H/HB-8000C-A Closet 1” 1-1/2” 1.6 GPF
H/HB-8-128 Closet 1” 1-1/2” 1.28 GPF
H/HB-8000C-B1 Urinal 3/4” 3/4” 1.0 GPF
H/HB-8000C-B2 Urinal 1” 1-1/4” 1.0 GPF
HB8RFKC-C/U Cl. & Ur. N/A N/A 0.5-3.5 GPF
ELECTRICAL REQUIREMENTS:
• AC Powered Units:
– Solenoid valve and sensor: 6V DC
– Transformer: Input 120V AC, 60 Hz
Output 12V DC
• Baery Powered Units
– Solenoid valve and sensor: 6V DC
– Baery: (4) AA Alkaline Baeries
– Baery Service Life:
◦ 400,000 ushes, up to 6 years (Baery)
◦ 650,000 ushes, up to 10 years (Solar)
BASIC PACKAGE INCLUDES:
H-8000C
(-A, -B1, -B2)
HB-8000C
(-A, -B1, -B 2)
HB8RFKC
(-C, -U)
HB-8000SLE
(-A, -B1, -B2)
(1) Flush Valve
9 9 9 9
(1) Stop Valve
9 9 9
(1) Sweat Kit
9 9 9
(1) Flush Tube
9 9 9
(1) Spud Coupling
9 9 9
(1) Vacuum Breaker
9 9 9
(1) AC Adapter
9
(1) AC Input Tube
9
(4) AA Baers
9 9 9
OPTIONAL ACCESSORIES:
• HC-010 Mul-Unit Power Adapter (AC only) - 8 units
• HC-0104 Mul-Unit Power Adapter (AC only) - 4 units
