H-8000C Series

Sensor Operated Flush Valve

Control Module

1 2 3

4

56789

LEGEND

1. DC Input Pin Receptor

2. Dip Switches

3. Reset Buon

4. Indicator Lights

5. Solenoid Pin Receptor

6. Control Cable (Sensor Eye) Pin Receptor

7. Sensor Distance Adjustment Dial

8. AC Input Pin Receptor

9. DC Input Pin Receptor
