深圳市宏宇达数控技术有限公司
地址：深圳市南山区中山园路 1001 号 E4-6C(TCL 国际 E 城) TEL：755-26625800 FAX：755-26729960
-2-
SAFETY：
Please read this manual fully before use XPTHC-4
DO NOT open cabinet of THC unless trained technician.
DO NOT adjust the sealed resister.
Turn off Powersupply if when THC is unused.
DO NOT put liquid on THC.
Attention Anti-dust work, DO NOT let metal dust into THC.
Installation Note：
Power supply: AC 24V or DC 24V
Please offer the enough power supply: usually, 25W motor, the current couldn’t be
less than 3A, the AC24V transformer couldn’t be less than 50W.
Power supply= 2*motor’s power + 10W
GND Must follow THC instruction, GND resister≤4Ω。
UP/DOWN on THC must be same to Z-axis Lifter
To avoid interference, follow cables please use shield cable( connection between
CNC controller and THC, to motor, to voltage divider, to IHS card), especially the
cable from THC to voltage divider, please use shield twisted pair cable, and shield
net connected at THC side.
The plasma raw arc couldn’t connect to the THC directly, must connect to the
voltage divider correctly.
To Customer：
We only supply to re-seller as CNC cutting machine manufacturer, engineering
company… end-user please contact our local distributor for product
supplying.
We offer technical support to all distributors and users of our product.
。
IMPORTANT NOTE
：
All our THCs have been tested on CNC cutting machine in our workshop
before delivery, all commissioning work was done. Please DO NOT change the
setting without informing your supplier.
ShenZhen HYD CNC Technology CO.,LTD
