Hypertec CIARA Horizon 8175 - Horizon 8275 HDD and SSD

5.2. Horizon 8275 HDD and SSD
To remove the 3.5” HDD, lift the tab
and pull out the drive.
To remove the 2.5” HDD or SSD,
unscrew the retaining screw and
remove the drive.
To remove the M.2 SSD, unscrew the
retaining screw, lift the drive and pull
it out of the slot.
Page 10 of 14
