8. Processor
8.1. Horizon 8175 processor
8.2. Horizon 8275 processor
To remove the processor, turn the 4
latches counterclockwise, open the
lever, lift the cover and remove the
processor.
To remove the processor, turn the 4
latches counterclockwise, open the
lever, lift the cover and remove the
processor.
Page 13 of 14
