Hypertec CIARA Horizon 8175 - 5 Hard Disk Drive and SSD; Horizon 8175 HDD and SSD

5. Hard disk drive and SSD
5.1. Horizon 8175 HDD and SSD
To remove the 3.5” HDD, press the
latch and pull out the drive.
To remove the 2.5” HDD or SSD, press
the latch and pull out the drive.
To remove the M.2 SSD, unscrew the
retaining screw, lift the drive and pull
it out of the slot.
To remove the 2.5” HDD or SSD, press
the latch and pull out the drive.
Page 9 of 14
