HYQUEST SOLUTIONS PTY LTD
Tipping Bucket Raingauge TB3 100-07 Issue 12: 29/7/2014
VI. MAINTENANCE
The only routine maintenance required is cleaning. The following items should be checked
regularly for cleanliness:
Catch filter
Syphon (refer diagram 2)
Interior of bucket
Ensure Rain Gauge is level using the bubble level fitted to the base
Enclosure locking screws - lightly lubricate after cleaning
All insect screens
i. Dismantle Details
(a) Unscrew nut
(b) Lightly press stem down on surface until stem pops out of syphon body.
(c) Remove stem from syphon body.
(d) Unscrew cap
(e) Clean all items
Push Filter
Pull
Syphon
To dismantle the Filter & Syphon
Assembly. Push filter and pull
syphon at the same time. Do not
twist.
Do not twist
while pushing &
pulling
To Next Page
