TM-600 Mobile Radio
6
Rear Panel View
1） 15-Pin Connector (for external expansion)
2） External Speaker Jack
Used to connect the external speaker (for the 3.5mm plug only).
Note: Please refer to “Test Cable for Speaker Output” in “Tuning Description” for details.
3） Power Inlet
Used to connect the HYT-authorized DC power cable for input of 13.6V DC power.
4） Antenna Connector
Used to connect the external connector.
Microphone
8-segment Numeric LED Display
