UHF1 (400-470MHz) Information Service Manual
120
Description of Normal Situations:
[1] During transmission, output voltage by Q107 PIN3: about 4V.
During reception, output voltage by Q106 PIN3: about 4V.
[2] During transmission, voltage at Q108 E: about 1.8V.
During reception, voltage at Q104 E: about 1.8V.
[3] The CV value varies with frequencies. Generally, it is within the range 0.5V-4.5V.
[4] L110/L116 is on.
[5] Voltage at Q101/Q102 B: about 0.7V.
[6] MCSI-CLK-PLL outputs 960 KHz clock.
To Next Page
