Hytera MD61X - Rear Panel; Programmable Keys; LCD Icon

3
2.2 Rear Panel
No.
Part Name
No.
Part Name
1
RF Antenna Connector (BNC
female)
3
Accessory Connector
2
Power Inlet
4
GPS Antenna Connector (SMA
female)
Note: The GPS antenna connector is available for MD61X mobile radios only.
2.3 Programmable Keys
For enhanced convenience, you may request your dealer to program the SK1, SK2, P1, P2 and P3 keys
as shortcuts to certain feature.
2.4 LCD Icon
Icon
Radio Status
Blue Tooth is open and connet
Low TX power for the current channel.
High TX power for the current channel.
Digital channel
Analog channel
The Monitor feature is active.
The radio is in emergency state or an emergency call is received.
