No. Part Name No. Part Name
8 OK/Menu Key 19 Down Key
9 P1 Key 20 Battery Latch
10 Speaker 21 Belt Clip
11 Numeric Keypad 22 Battery
Note
For enhanced convenience, you may request your dealer to program the TK, SK1, SK2, P1, and P2
as shortcuts to radio features. For the detailed introduction, see the DMR Conventional Radio
Feature Description and Operation Manual along with the product.
2.2 LCD Icon
Icon Radio Status
The DTMF keypad is enabled.
The GPS feature is enabled, and the radio receives GPS data.
The GPS feature is enabled, but the radio receives no GPS data.
The number of bars (0–3) indicates the charge remaining in the
battery.
The radio is set at Low power.
The radio is set at High power.
An accessory is connected.
One or more new work orders are received.
The maximum number of saved work orders is reached.
Direct Mode: In this mode, radios communicate with each other
directly.
Repeater Mode: In this mode, radios communicate with each
other via a repeater.
The Monitor feature is enabled.
The radio is in emergency mode (excluding silent emergency
