3-1
GROUP 1 STRUCTURE AND OPERATION
SECTION 3 POWER TRAIN SYSTEM
Drive axle
Propeller shaft
Transmission
Torque converter
Steering axle
Engine
110D7EPT01
The power train consists of the following components :
· Torque converter
· Transmission
· Propeller shaft
· Drive axle
Engine power is transmitted to the transmission through the torque converter.
The transmission is a hydraulically engaged three speed forward, three speed reverse power shift type
transmission.
The transmission outputs through universal joints to drive axle assembly.
The power transmitted to front axle drives front wheels.
11. POWER TRAIN COMPONENT OVERVIEW

Hyundai 160D-7E Specifications

General

Model	160D-7E
Capacity	16000 kg
Engine	Cummins QSB6.7
Power Type	Diesel
Engine Model	Cummins QSB6.7
Tire Type	Pneumatic
Fuel Type	Diesel
Engine Power	157 kW
Fork Length	2, 400 mm
