GROUP 1 STRUCTURE AND FUNCTION
SECTION 6 HYDRAULIC SYSTEM
1. HYDRAULIC CIRCUIT
T
M
P
T
LS P
L
R
10 MPa
2A
2B
3A
3B
4A
4B
1A
LS
EF
CF
P
3
4
9
8
65
2
1
10
7
11
LIFT TILT AUX 1 AUX 2
22B7HS01
1 Hydraulic gear pump with priority valve
2 Main control valve
3 Steering unit
4 Steering cylinder
5 Tilt cylinder
6 Lift cylinder
7 Suction strainer
8 Down control valve
9 Down safety valve
10 Return filter
11 Hydraulic oil tank
