3-16
Safety system
Rear seat headrests
OBC3030009
OBC3030009
The rear seats are equipped with
headrests in all the seating positions for
the passenger’s safety and comfort.
OAI3039008
OAI3039008
Adjusting the height up and down
To raise the headrest:
1. Pull it up to the desired position (1).
To lower the headrest:
1. Push and hold the release button (2)
on the headrest support.
2. Lower the headrest to the desired
position (3).
OBC3030036TU
OBC3030036TU
Removal and installation
To remove the headrest :
1. Raise the headrest as far as it can go.
2. Press the release button (1) while
pulling the headrest up (2).
To reinstall the headrest :
1. Put the headrest poles into the holes
(3) while pressing the release button
(1).
2. Adjust the headrest to the appropriate
height.
