1
CONTROLS AND EQUIPMENT
11
2. Remove the old battery from the
case and note the polarity. Make
sure the polarity of the new battery
is the same(+side facing up), then
insert it in the transmitter.
3. Installation is the reverse order of
disassembly.
NOTE:
Install a new battery within 30 sec-
onds after remove the old one, if
installing a new battery takes more
than 30 seconds, take the following
steps.
1) Turn the ignition key to the "ACC"
position.
2) Make sure that the turn signal
lights blink once by pushing the
"LOCK" or "UNLOCK" button on
the transmitter.
Battery
OGK016121
POWER WINDOWS
B050A03GK-EAT
The power windows operate only when
the ignition key is in the "ON" position.
The main switches are located on the
driver's arm rest and control the front
windows on the respective sides of the
vehicle. The windows may be opened
by depressing the front portion of the
switch. To stop at the desired opening,
release the switch. The window may
be closed by pulling the front portion of
the switch. To open the window on the
driver's side, press the switch(1) half-
way down. The window moves as long
as the switch is operated.
To fully open the driver's window auto-
matically, press the switch fully down.
In automatic operation, the window will
fully open even if you let go of the
switch. To stop at the desired opening,
pull up and release the switch.
In order to prevent operation of the
passenger front and rear windows, a
window lock switch(2) is provided on
the armrest of the driver's door. To
disable the power windows, press the
window lock switch. To revert to normal
operation, press the window lock switch
a second time.
HGK2015R-1
(2)
(1)
