Hyundai KONA 2021 - Infotainment

INFOTAINMENT
Quick Reference Guide I 1817 I Quick Reference Guide
KONA
HYUNDAI
STEERING WHEEL AUDIO CONTROL
1
VOLUME
Raises or lowers the speaker volume.
2
SEEK / PRESET
Changes the station.
3
MODE
Changes the audio source.
4
MUTE
Press to Mute.
MUTE
MUTE
MUTE
2
2
3
3
1
1
Type A
Type B
4
4
BLUETOOTH PHONE PAIRING
1. Press the SETUP
A
button.
2. Press the “Bluetooth” button on the screen.
3. Press “Add New” button on the screen.
4. Search for the device name as displayed on
your mobile phone and connect.
5. If necessary, input the passkey displayed on
the Audio screen.
6. Pairing is complete.
NOTE : Vehicle must be parked to complete the pairing process.
SEEK
RADIO
MEDIA
TUNE
FILE
ENTER
SETUP
PHONE
HOME
TRACK
VOL
PWR
PUSH
A
To switch between phones:
1. Push the ‘Setup’ button.
2. Select Bluetooth.
3. Select Bluetooth Connections.
4. Select Connect next to the desired phone.
BLUETOOTH OPERATIONAL TIPS
To Answer a Call:
• Press the button on the steering wheel.
To Reject a Call:
• Press the button on the steering wheel.
To Adjust Ring Volume:
• Use the VOLUME buttons on the steering wheel.
To Transfer a Call to the handset (private mode):
• Press and hold the button on the steering wheel until the audio
system transfers a call to the phone.
To Finish a Call:
• Press the button on the steering wheel.
In the following situations you or the other party may have difficulty hearing
each other:
1. Keep the Bluetooth volume low. High level volume may result in distortion
and echo.
2. When driving on a rough road, high speeds and/or with the window open.
3. When the air conditioning vents are facing the microphone located at the
headliner and/or when the air conditioning fan is at the max speed.
Steering wheel bluetooth control
1
VOICE RECOGNITION
Activates the voice recognition.
2
CALL
Places and transfers calls.
3
END
Ends calls or cancels functions.
MUTE
MUTE
3
2 3
2
1
