[Important]
・If you do not press the [Set] buttons, the settings will not be confirmed.
[Note:]
・[New X Fixed-8MP][New X Fixed-6MP]If [Image capture mode] is set to [60fps
Mode] or [50fps Mode], [SCD] cannot be used.
[Important]
・In the following cases, the undesired signal detection function will not work for a
while.
After turning on the power
-after changing the undesired detection setting
-when the image angle of the machine changes
・When a disturbance is detected using the disturbance detection function, [Alarm
notification] is displayed for confirmation.
→2.3.2 About live image pages
・[Alarm notification] is also displayed when an alarm input is received with a
terminal alarm or other alarm such as an operation detection alarm is generated.
4 To disable the motion detection area, change the [Status] of the area in question to [Off] and
click [Set]. The disabled box will be dotted.
When disabled, no alarm is generated even if there is a change in the area.
5 To delete an area for motion detection, click [Delete] in the area to delete to delete the area
frame.
6 When [Set] is clicked, the settings are reflected in the computer.
12.7 [SCD area] to set up undesired detection
This section sets the disturbance detection function.
The jamming detection function activates an alarm when the camera detects a change in the
subject by covering the camera with a cloth or a lid or changing the orientation of the camera
significantly. You can set up one area. When disturbance is detected in the set area, an alarm is
activated.
12 [Alarm] to set the alarm
12.7 [SCD area] to set up undesired detection
