I-Semble REVISED VERTICAL MURPHY BED - Page 5

5
Twin Qty. Full Qty. Queen Qty.
S2 #5 Allen Key 1 1 1
T Threaded Inserts 16 16 16
U M8 x 16mm Hex Head Screws 16 16 16
V #10 x 55mm Flathead Screws 26 26 26
W #8 x 15mm Washer Head Screws 28 48 48
Z M5 x 15mm Machine Screw 2 2 2
AA M6 x 30mm Bolts 4 4 4
BB M8 x 50mm Bolts 34 34 34
DD Nylon Washers for Legs 4 4 4
EE M5 Nuts (for Saddle Lock) 2 2 2
FF M8 Lock Nuts 40 40 40
GG Temporary Stop (styrofoam) 2 2 2
HH Wall Brackets 2 2 3
II 1/4"-20 Allen Head Screw 2 2 3
JJ #12 x 3/4" Washer Head Screw 4 4 6
KK 1/4" x 3" Washer Head Lag Bolt 8 8 12
NN #4 Allen Key 1 1 1
G1
N
R
NN
S2
JJ
T
U
EE
DD
FF
J
BB
AA
Z
W
V
KK
II
