I-Tech MAG700 - Technical Features

IACER Srl 6 MNPG69-09
MAG700 is a device intended for both the professional user (physician,
therapist, etc.) and the patient at home. In case of home therapy, the use
of the device is recommended only on indication of the
physician/therapist.
The patient population intended for magnetotherapy treatment using the
MAG700 device includes patients of both sexes, men and women, of age
(unless otherwise indicated by medical doctors). For further details, please
refer to the Contraindications section.
Technical features
Characteristics
Specification
Power supply
GJ24WA-1500120V, output 15V DC, 1.2A
Max. absorbed current
0,8A
Isolation class (EN 60601-1)
II
Applied part (EN 60601-1)
BF
Dimensions (length x width
x height)
179x107x50 mm
Field intensity
Adjustable on increasing level up to 70
Gauss
Squared wave frequency
Adjustable 5-100Hz
Therapy time
Adjustable by the user (max 12
consecutive hours)
Environmental conditions of
operation
Temperature
From +5 to + 28 °C
Relative humidity
From 15 to 93%
Pressure
From 700 to
1060hPa
ATTENTION! The device delivers current above 10mA.
Maximum magnetic field intensity is 70 Gauss with elastic
therapeutic band. Intensity, frequency and time values are given with
±20% of accuracy.
Expected life of the device and its accessories: 2 years.
