IACER Srl 17 MNPG148-06
Electrodes’ positioning and intensity levels
The electrodes have to be positioned to form a square over the painful zone by
using the channel 1 and 2 as shown above in Figure 1 (red or black up or down
are not important for the therapy purposes, follow the indications in the
Positions manual). The intensity should be adjusted to a level between the
thresholds of perception and pain: the maximum intensity level is the moment
in which the muscles surrounding the treated area begin to contract; over this
limit the stimulation does not become more effective, just more irritating, so it
is best to stop before that point.
Programs specifications
Prg
Medical
prg.
Yes/No
Description PHASE 1 PHASE 2 PHASE 3
1 Yes
Conventional
Tens (fast)
Total time 40
min
frequency 90 Hz
impulse width
50µs
2 Yes
Endorphinic Tens
(delayed)
Total time 30
min
frequency 1 Hz
impulse width
200µs
3 Yes
Tens at
maximum values
Total time 3 min
frequency 150
Hz
IMPORTANT
Create a square area with the
electrodes over the painful zone.
Keep 4cm minimum distance
between the electrodes.
Figure 1 – Electrodes’ positioning.
