I-Tech MIO CARE PRO - Device and commands description

IACER Srl 7 MNPG148-06
Characteristics
Specifications
Command
ABS keyboard with 9 keys
Conditions of use
Environmental
temperature
From +5° to +40°C
Relative humidity
From 30% to 75%
Atmospheric
pressure
From 700 to 1060hPa
Storage and transportation
conditions
Environmental
temperature
From -10° to +55°C
Relative humidity
From 10% to 90%
Atmospheric
pressure
From 700 to 1060hPa
WARNING: the device has an output current over 10mA.
* Use only the battery recharger given by the manufacturer. The use of other
recharger could seriously compromise the security and safety both of the
patient and of the device.
Expected useful life of the device is set in 3 years, meanwhile the expected
useful life of the electrodes is set in 10/15 uses.
Device and commands description
1. CH1 output
2. CH2 output
3. Battery charger connector
