I-Tech Power Q-6000 Plus - Specifications; Technical Specifications; Purpose

IACER SRL Page 8 di 22 MNPG80-01 of 06/05/2016
Extensions:
 Max. width around 13 cm
 Min. width around 6 cm
Specifications
Power Q-6000 Plus has the following specifications:
 Class IIa equipment (Directive 93/42/EEC, annexed IX, rule
9);
 Class I, applied part type BF (Classif. CEI EN 60601-1);
 Equipment not protected against liquids penetration;
 Equipment and accessories not subjected to sterilization;
 Use of the equipment is prohibited close to flammable
substances or in environments with high concentrations of
oxygen;
 Continuous operating mode equipment;
 Equipment not suited to be used in external.
Technical Specifications
Power supply
220-240 VAC,
50-60 Hz
Therapy time
Adjustable (0
÷99 minutes)
Max output
power
80 VA
Max
pressure
240 mm Hg
(±10%)
Weight
9,5 Kg
Purpose
Clinical purpose: Therapeutic
Use: Clinic and domestic use
