TREATMENT PRG
HANDLE
POSITION
FREQ
DUTY
CYCLE
TIME HEAD
SUGGESTED
INTENSITY
APPLICATIONS
NUMBERS
Carpal tunnel
syndrome
U-01/10 Internal wrist 1MHz 40% 15min 5cm²
1.0W/cm² -
1.5W/cm²
10-15
Vascularisation U-01/10 Affected area 1MHz 60% 15min 5cm²
1.0W/cm² -
1.5W/cm²
Free
Active principle
vehiculation
U-01/10 Affected area 1MHz 60% 15min 5cm² 2W/cm² Free
Indications regarding intensity and number of sessions can vary depending on the opinion of your personal doctor
or therapist.
In particular, the indications on intensity do not consider the width of the area to be treated. If this is very wide, the
intensity of the ultrasound can be increased by 20% with respect to what indicated above or, vice versa, it can be reduced, if
the area is small. Similarly, the movement on the area must be appropriate to the heat felt by the patient: the slower it’s been
moved, the stronger the heat. If the patient complains about the heat, we advise reducing the intensity or moving the head
faster.
REMEMBER TO:
• keep moving the ultrasound head and uniformly apply the treatment on the overall area;
• use enough gel in order to guarantee a proper contact.
