1. Specification
GSM module MTK program, GSM 850/900/1800/1900
Support TCP protocol
GPS Chipset U-BLOX 7020(Support GPS/Glonass/Galileo/Compass)
GPS sensitivity -162dB
Hot start 1sec.,average
Warm start 30 sec.,average
Cold Start 35 sec, average
Altitude Limit 18,000 meters (60,000feet) max.
Operating temperature -20°C－65°C
Battery Volume 150mAh
Dimension 89mm×51mm×15mm
Voltage 10V – 45V
2. Wiring connections
Red (+)12V -24V
Black GND(-)
Yellow: connect with car ACC
Blue LED Light--- GPS Status
Status Meaning
Flash No gps signal, or searching for gps signal
Always on GPS Signal ok
