INSTALLATIONS
10 MB820 User’s Manual
JP7: DiskOnChip Address Select
JP7 Address
D0000-D7FFF
D8000-DFFFF (default)
JP8: Onboard VGA Enable/Disable
Use JP8 to enable or disable the onboard VGA controller.
JP8 Setting Onboard VGA
Pin 1-2
Short/Closed
Enabled
Pin 2-3
Short/Closed
Disabled
