IBC HPX 3 - Page 16

Wiring connection area Outdoor finned coil
Electrical connection rubber grommet (2) Return water connection
Supply water connection Fan (1 of 2)
Heat Exchanger Compressor
Figure 8 Interior view of HPX 5
16
Section: Introduction
