IBC HPX 3 User Manual

Name: IBC HPX 3
Brand: IBC
Rating: 4 (1 reviews)

68 pages

To Next Page

To Previous Page

HPX 5 parts diagram

10 Front door, HPX 5 P-1922 1

20 Axial fan grill cover, HPX 5 P-1916 2

30 Axial fan blade, HPX 5 P-1914 2

40 Axial fan DC motor, HPX 5 P-1912 2

Section: Exploded views of the HPXseries Heat Pumps
