 The middle and outside clamps can be inserted into the carrier rail directly from the top, into the
position where they are required.
 The middle clamp G4 is swiveled into the carrier rail, where it is needed
Important!
The slot nut of the G4 clamp must be aligned as shown in the Figure 93 and must not be installed twisted.
Figure 93 Inserting middle clamps G4
Figure 92 Inserting middle clamps G3
