DIP SWITCH
Cleaning function Cleaning function set to ON position.
When the wheel has stopped for 30 minutes, the cleaning function is
activated and the wheel rotates at minimum rpm for 10 seconds.
Rotation monitor Rotation monitor set to ON position.
High speed*) e wheel rotates at the set maximum rpm when the switch is set to ON.
Aer a test run, make sure the DIP switch is set to OFF.
Low speed*) e wheel rotates at the xed minimum rpm when the switch is set to
ON.
Aer a test run, make sure the DIP switch is set to OFF.
*) Manual operation (test mode)
OPERATIONAL INDICATIONS
On/alarm ON is lit continuously.
Flashes when the control unit has tripped.
Run Comes on when the motor is to rotate, i.e. when the input signal exceeds
the threshold value.
Rotation Flashes when the magnet passes the magnetic sensor, regardless of the
“Rotation monitor” DIP switch setting.
Flashes even if the input signal is lower than the threshold value.
7
