42 43
DVO JADE X
DVO worked with our National Enduro Team and
our engineers to come up with a damping profile to
match the new Ripmo and Ripmo AF kinematics.
The Jade X features a 3 position compression
adjuster that allows the rider to choose from
full open (descending) mid position (single
track or climbing) to near lock out for the
3rd position.
They also came up with a new rebound
damping profile that has built in low speed
rebound during the initial part of the
suspension movement, keeping the bike
feeling composed and balanced. The middle
part of the rebound stroke (the sweet spot)
allows for rapid movement which keeps
the rear wheel tracking the ground without
packing down and the end of stroke slows
down again reducing the possibility of getting
bucked during jumps or larger impacts.
The Topaz has a three position compression damping switch.
As with all of our dw-link bikes, we prefer to run them WFO
(wide open) and let the dw-link do its magic.
For rebound, adjust to personal preference, as outlined on
page 27.
27.5% SAG / 14MM
RIDER WEIGHT PRESSURE
LB PSI
120-130 112-123
130-140 123-134
140-150 134-144
150-160 144-155
160-170 155-166
170-180 166-177
180-190 177-187
190-200 187-198
200-210 198-209
210-220 209-220
220-230 220-230
230-240 230-241
240-250 241-252
COIL SPRING WEIGHT GUIDE
RIDER WEIGHT SPRING WEIGHT
LB LB
140-155 350
155-170 400
170-185 450
185-200 500
200-215 550
215-230 600
NOTE: Ripmo AF ships with the following
standard coil springs
Small: 350
Medium: 400
Large: 450
X-large: 500
25% SAG - Shoot for .45” (~11mm) of sag.
RIDER WEIGHT PRESSURE
LB PSI
100 130
120 150
140 170
160 190
180 210
200 240
220 270
250 310
MAX 350 PSI!
25% SAG - Shoot for .47” (~12mm) of sag.
RIDER WEIGHT PRESSURE
LB PSI
100 120
120 140
140 160
160 200
180 200
200 230
220 260
250 300
MAX 350 PSI!
RIDE
STARTING PRESSURES FOR SETTING SAG
