©Copyright LOTRONIC 2016 QUAD8-FX Page 6
Display Reverse 180°
1. Press the either the MENU button until “DISP” is displayed, press ENTER.
2. Press the UP button to select “DSIP” to reverse the display, or “DISP” to change the display back.
3. Press ENTER to confirm.
Self test program
1. Press the MENU button until “TEST” is displayed, press ENTER.
2. The fixture will now run a self test. Press MENU to exit.
Reset
1. Press the MENU button until “Reset” is displayed. Press the ENTER button and the unit will reset itself.
DMX CHANNELS
11 channel definition table
Channel DMX Value Function
1 0---255 X motor route
2 0---255 Y1 motor route
3 0---255 Y2 motor route
4 0---255 Dimmer 0-100%
5
Strobe
000-007 Close strobe
008-015 Open strobe
016-131 Strobe from slow to fast
132-139 Open strobe
140-181 fast open slow close
182-189 Open strobe
190-231 Slow open fast close
232-239 Open strobe
240-247 Random strobe
248-255 open strobe
6 0---255 Red dimmer
7 0---255 Green dimmer
8 0---255 Blue dimmer
9 0---255 White dimmer
10 0---255 Y1, Y2 speed
11
000-007 Only others channels can be controlled
008-063 Auto run
064-127 Sound active
128-255 Reset
