IBM 1500VA LCD 2U Rack Uninterruptible Power Supply for IBM System x 6
Table 3. Specifications (continued)
Specification IBM 1500VA LCD 2U Rack UPS
(100V/120V)
IBM 1500VA LCD 2U Rack UPS
(230V)
Communications and management
USB HID port Yes Yes
RS-232 serial port Yes Yes
Ethernet port Optional using Network Management Card, 46M4110
Environmental Monitoring Probe Optional Environmental Monitoring Probe, 46M4113
Management software included IBM UPS Manager
Control panel Intelligent three-button, dual color, backlit graphical LCD displays vital UPS
status in nine languages
Audible alarm Alarm when on battery: Distinctive low-battery alarm
Remote Power Off (REPO) REPO port
Surge Protection and Filtering
Surge energy rating 1200 Joules 2400 Joules
Filtering ANSI/IEEE C62.41; 1991 CATEGORYB3 (SURGE)
Table 4 lists the expected period that the UPS will operate solely on batteries.
Table 4. IBM 1500 UPS runtime chart
Load (%) Load (VA) Load (Watts) Run time (minutes)
25 375 VA 250 W 14
50 750 VA 500 W 11
75% 1125 VA 750 W 7
100% 1500 VA 1000 W 5
Note: Battery backup times are approximate and may vary with equipment, configuration, battery age,
and temperature. The IBM 1500VA LCD 2U Rack UPS does not support Extended Battery Modules
(EBMs).
Physical specifications
Height: 84 mm (3.3 in)
Width: 438 mm (17.2 in)
Depth: 470 mm (18.5 in)
Weight: 5395-1AX - 18.4 kg (40.5 lb), 5395-1KX - 19.5 kg (42.9 lb)
