Connector locations for the 5147-024, ESLL, and ESLS storage
enclosures
Learn about connector locations for the 5147-024, ESLL, and ESLS storage enclosures.
Note: The T1 connectors are not used.
Connector locations for the 5148-22L, 8247-21L, 8247-22L, 8284-21A,
and 8284-22A systems
Learn about connector locations for the 5148-22L, 8247-21L, 8247-22L, 8284-21A, and 8284-22A systems.
The expanded function 5148-22L, 8247-21L, 8247-22L, 8284-21A, and 8284-22A servers provide cable
connector locations via a SAS port for disk drive enclosures.
Connector locations for the 8286-41A system
Learn about connector locations for the 8286-41A rack-mounted and stand-alone models.
The 8286-41A server provides cable connector locations via a SAS port for disk drive enclosures.
Figure 26. Connector locations for the 5147-024, ESLL, and ESLS storage enclosures
Figure 27. Connector locations for the expanded function 5148-22L, 8247-21L, 8247-22L, 8284-21A, and 8284-22A
systems
