Connector locations for the 8247-42L and 8286-42A systems
Learn about connector locations for the 8247-42L and 8286-42A rack-mounted models.
The 8247-42L and 8286-42A (expanded function) servers provide cable connector locations via a SAS port
for disk drive enclosures.
Figure 28. Connector locations for the rack-mounted 8286-41A (expanded function) system
Figure 29. Connector locations for the stand-alone 8286-41A (expanded function) system
32 Power Systems: Installing the Model 024, ESLL, or ESLS storage enclosure
