Item Description Item Description

1 Rack 9 Brace hinges

2 Bracket screw, M5 x 16 mm 10 Brace

3 Bracket 11 Side-cover securing screw mount

4 Brace latch bracket screw, M8 x

20 mm

12 Spacer

5 Brace latch bracket 13 Spacer screw, M8 x 20 mm

6 Hinge 14 Side cover washer

7 Hinge screw, M8 x 20 mm 15 Side cover securing screw, M5 x

16 mm

8 Brace thumbscrew

Figure 58. Ruggedized kit parts, feature code 6080

To remove the triangular brace, complete the following tasks:
