44V3429 - Two drive slide assembly rails
1621187 - Four flat blade screws
Removable disk drives
Table 65. Removable disk drives
Feature code Part number Description
1106 46C5375 160 GB Removable Disk Drive
1107 46C5379 500 GB Removable Disk Drive
EU01 46C2335 1 TB Removable Disk Drive
EU08 46C5377 320 GB Removable Disk Drive
EU15 46C2831 1.5 TB Removable Disk Drive
Purchasing additional removable disk drives
For best results, use only the removable disk drives that are shown in Table 65.
The removable disk drives are a supply item that can be ordered as a feature code. To order in the United
States and Canada, call 1-888-IBM-MEDIA. To order drives in other locations, contact your local provider
of IBM storage products or see Storage Media (http://www.storage.ibm.com/media/).
The removable disk drives are not a service item. IBM service representatives are not dispatched to
service or replace the removable disk drives.
Storing removable disk drives
Store removable disk drives in their protective containers, on a flat surface with the top side up. The
storage area must be clean and dry, must have normal room temperature, and be away from any
magnetic fields. For best storage life, use the removable disk drives every six months.
Supported SATA adapters and cables
The docking station only supports the SAS/SATA cable that is provided as part of the feature code.
Specifications
Interface
SATA
Bootable
Yes
Physical form factor (internal docking station)
5.25 inch half high
Environmental
SATA Removable Disk Drive Operating conditions Non-operating conditions
Temperature 5 to 55 C –40 to 65 C
Relative humidity 8 - 90% noncondensing 5 - 95% noncondensing
Maximum wet bulb temperature 29.4 C noncondensing 40 C noncondensing
Maximum temperature gradient 20 C per hour 20 C per hour
Altitude –300 to 3048 m (10,000 ft) –300 to 12,192 m (40,000 ft)
Managing devices 91
