IBM 8286-41A User Manual

Cabling the server and setting up a console
Your console, monitor, or interface choices are guided by whether you create logical partitions, which
operating system you install in your primary partition, and whether you install a Virtual I/O Server
(VIOS) in one of your logical partitions.
P7EF3502-2
1
D
A
C
Figure 15. Sliding the cable-management arm tab into the mounting bracket slot
P7EF3503-1
2
E
D
Figure 16. Sliding the other cable-management arm tab into the extension bracket
Installing the IBM Power System S814 (8286-41A) 11

IBM 8286-41A Specifications

General

Processor	POWER8
Operating System	AIX, IBM i, Linux
RAID Support	RAID 0, 5, 6, 10
Processor Cores	Up to 24 cores per processor
Model	8286-41A
Number of Processors Supported	2
Network Interface	Gigabit Ethernet
Power Supply	Dual redundant power supplies
