3. Remove all fans from the server
4. Remove all memory cards from the server.
5. Remove the microprocessor tray:
a. Open the microprocessor-tray release latch (1).
Microprocessor-tray
lever
Microprocessor-tray
lever
Microprocessor-tray
retention latch
(both sides of tray)
Air baffle
Microprocessor-tray
release latch
Chapter 2. Installing options 17
