Server replaceable units
Notes:
1. Field replaceable units (FRUs) must be serviced only by trained service
technicians.
2. Customer replaceable units (CRUs) can be replaced by the customer. Tier 1
CRUs and Tier 2 CRUs are described in the IBM “Statement of Limited
Warranty” (at “Part 3 - Warranty Information”), which is in the Warranty and
Support Information document on the IBM System x Documentation CD.
Table 3. Parts listing, Type 8864
Index Description
CRU No.
(Tier 1)
CRU No.
(Tier 2) FRU No.
1 Top cover (all models) 26K8947
2 Power supply, 1300 W (all models) 24R2723
3 Power supply structure (all models) 26K8950
4 Power backplane (models 1Rx, 1Tx, 2Rx, 2Tx, 3Rx, 4Rx,
5Rx)
41Y3188
5 PCI board assembly (models 1Rx, 1Tx, 2Rx, 2Tx, 3Rx,
4Rx, 5Rx)
40K0282
6 PCI switch card assembly (all models) 39M2699
7 Chassis assembly (all models) 42D3935
8 Fan (92 mm) (all models) 39M2694
9 Carrier, LP/media (all models) 42D3936
10 CD drive, 8/24X (primary) (all models) 39M3541
10 CD drive, 8/24X (alternate) (all models) 39M3563
10 CD drive, 24X (optional) 26K5427
10 CD drive, 24X (optional) 39M3559
10 CD drive, 127MM (optional) 39M3529
10 CD drive, 127MM (optional) 39M3567
10 CD-RW drive, 14X (optional) 39M3503
10 DVD drive (optional) 42C0955
11 Microprocessor VRM, 10.2 (optional) 39Y7256
12 Microprocessor tray (all models except 1Tx, 2Tx, EAx,
EBx, EDx)
40K2470
12 Microprocessor tray (models 1Tx, 2Tx, EAx, EBx, EDx) 44E4281
13 x3850 bezel (all models) 42C2614
14 Microprocessor, 2.5 GHZ (models 1Rx, 1Tx, E1x, E2x) 42D3357
14 Microprocessor, 3.0 GHZ (models 2Rx, 2Tx, E4x) 42D3359
14 Microprocessor, 3.16 GHZ (models 3Rx, E3x) 42D3361
14 Microprocessor, 3.33 GHZ (model 4Rx) 42D3363
14 Microprocessor, 3.5 GHZ (model 5Rx) 43W9473
15 Heat sink (all models) 26K8805
16 Microprocessor baffle (all models) 26K9020
17 Hard disk drive filler (all models) 26K8680
24 IBM System x3850 Type 8864: Problem Determination and Service Guide
