Table 45. Dimensions for rack (continued)
Width Depth Height Weight (Empty)
Weight
(Maximum
conguration)
EIA unit
capacity
Note: When the rack is delivered or is moved, outriggers are needed for stability. For more information about
outriggers, see Side stabilizing outriggers.
Table 46. Dimensions for doors
Door model Width Height Depth Weight
Standard front
door (FC EC01)
and
standard back
door (FC EC02)
597 mm (23.5
in.)
1925 mm (75.8 in.) 22.5 mm (0.9 in.) 7.7 kg (17 lb)
Triplex door (FC
EU21)
3
597.1 mm (23.5
in.)
1923.6 mm (75.7 in.)
105.7 mm (4.2 in.)
1
16.8 kg (37 lb)
128.3 mm (5.2 in.)
2
1
Measured from the front flat surface of the door.
2
Measured from the IBM logo on the front of the door.
3
Multiple racks that are placed side-by-side must have a 6 mm (0.24 in.) minimum clearance between racks to
allow the triplex front door to hinge properly. Feature code EC04 (Rack suite attachment kit) can be used to
maintain the 6 mm (0.24 in.) minimum clearance between racks.
Table 47. Dimensions for side covers
1
Depth Height Weight
885 mm (34.9 in.) 1870 mm (73.6 in.) 17.7 kg (39 lb)
1
Side covers do not increase the overall width of the rack.
Table 48. Temperature requirements
Operating Nonoperating
10°C - 38°C (50°F - 100.4°F)
1
-40°C to 60°C (-40°F to 140°F)
1
The maximum 38°C (100.4°F) temperature must be derated 1°C (1.8 °F) per 137 m (450 ft) above 1295 m
(4250 ft).
Table 49. Environmental requirements
Environment Operating Nonoperating Maximum altitude
Noncondensing humidity 20% - 80% (allowable)
40% - 55%
(recommended)
8% - 80% (including
condensing)
2134 m (7000 ft) above
sea level
Wet bulb temperature 21°C (69.8°F) 27°C (80.6°F)
Site and hardware planning 39
