Bezel
Release tabs
3. Remove components from the rear of the BladeCenter S chassis.
a. Remove all power modules.
Power module 3
Power module 4
Release handle
(open)
b. Remove all fan modules.
Chapter 2. Installing the BladeCenter S Types 7779 and 8886 31
