Feature codes for overhead cable management (top-exit bracket):
Use this feature code to order cable management for overhead cabling (top exit
bracket) for your storage system.
Note: In addition to the top-exit bracket and top-exit power cords, one IBM
approved ladder (feature code 1101) must also be purchased for a site where the
top-exit bracket for fiber cable feature is used. The IBM approved ladder is used to
ensure safe access when your storage system is serviced with a top-exit bracket
feature installed.
Table 73. Feature codes for the overhead cable (top-exit bracket)
Feature Code Description
1400 Top-exit bracket for fiber cable
Overhead cabling installation and safety requirements:
Ensure that installation and safety requirements are met before your storage
system is installed.
Figure 14. Top exit feature installed (cable routing and top exit locations)
134 DS8880 Introduction and Planning Guide
