Meeting floor load requirements
It is important for your location to meet floor load requirements.
About this task
Use the following steps to ensure that your location meets the floor load
requirements and to determine the weight distribution area that is required for the
floor load.
Front
Rear
121.92 cm
(48 in)
front service
clearance
Swivel
casters
7.9 cm
(3.1 in)
4.83 cm
(1.9 in)
2.8 cm
(1.1 in)
12.45 cm
(4.9 in)
120.02 cm
(47.25 in)
59.94 cm
(23.6 in)
without
covers
Rear casters
fixed
2.8 cm
(1.1 in)
19.05 cm
(7.5 in)
4.83 cm
(1.9 in)
7.9 cm
(3.1 in)
76.2 cm
(30 in)
Rear service
clearance
f2c02270
1
2
3
4
5
6
7
7
4
4
4
5
Figure 17. Physical footprint. Dimensions are in centimeters (inches).
