IBM DS8884 Series

The following shows the receptacle or inline connector (the power source, a mirror
image of the plug).
G
f2c01862
Vac
C
Vac
B
A
Vac
Figure 27. Three-phase low voltage (200 - 240 V) 60A or 30A, IEC60309 cable connector
pins
Ground
Vac
Vac
Vac
Neutral
C
B
A
f2c01938
Figure 28. Three-phase high voltage (380 - 415 V) 30A, IEC60309 cable connector pins
G
Vac
f2c01859
B
A
Vac
Figure 29. Single-phase, 200 - 240 V, 60A, IEC60309 customer outlet pins
Chapter 6. Delivery and installation requirements 161
