Table 12. Components for the DS8886 (machine type 283x models 986 and 86E) (continued)
Processors
System
memory
Processor
memory
I/O enclosure
pairs
Host
adapters
(8 or 4
port)
Device adapter
pairs
Standard drive
enclosure pairs
1,
2
High
Performance
Flash Enclosure
Gen2 pairs
1, 2, 3
Expansion
frames
1. Standard drive and High Performance Flash Enclosures Gen2 are installed in pairs.
2. This configuration of the DS8880 must be populated with either one standard drive enclosure pair (feature code 1241) or one High Performance
Flash Enclosure Gen2 pair (feature code 1600).
3. Each High Performance Flash Enclosure Gen2 pair (feature code 1600) includes a pair of flash RAID adapters.
Table 13. Maximum capacity for the DS8886 (machine type 283x models 986 and 86E)
Processors
System
memory
Maximum
2.5-in.
standard
disk drives
Maximum
storage
capacity for
2.5-in.
standard
disk drives
Maximum
3.5-in.
standard
disk drives
Maximum
storage
capacity for
3.5-in.
standard
disk drives
Maximum
2.5-in. Flash
Tier 0, Flash
Tier 1, or
Flash Tier 2
drives
Maximum
storage
capacity for
2.5-in.Flash
Tier 0, Flash
Tier 1, or
Flash Tier 2
drives
Maximum
total drives
1
8-core 128 GB
256 GB
96 173 TB 48 288 TB 96 730 TB 192
16-core 256 GB
512 GB
1440 2.59 PB 720 4.32 PB 192 1459 TB 1632
24-core 1024 GB
2048 GB
1440 2.59 PB 720 4.32 PB 192 1459 TB 1632
1. Combined total of 2.5-in. disk drives and 2.5-in. Flash Tier 0, Flash Tier 1, or Flash Tier 2 drives.
Base frame (model 986) overview:
The DS8886 (model 986) includes a base frame.
The base frame includes the following components:
v Standard storage enclosures
v High Performance Flash Enclosures Gen2
v Hardware Management Console (HMC), including a keyboard and monitor
v Second HMC (optional)
v Ethernet switches
v Processor nodes (available with POWER8 processors)
v I/O enclosures
v Direct-current uninterruptible power supplies (DC-UPS)
v Rack power control (RPC) cards
Expansion frame (model 86E) overview:
The DS8886 supports up to four expansion frames (model 86E) that can be added
to a base frame (model 986). A minimum of 256 GB system memory and a 16-core
processor is required, if expansion frames are added.
The first expansion frame supports up to 192 2.5-inch standard disk drives. The
second, third, and fourth expansion frames support up to 384 2.5-inch standard
disk drives. When all four frames are used, the DS8886 can support a total of 1,440
2.5-inch standard disk drives in a compact footprint, creating a high-density
storage system and preserving valuable floor space in data center environments.
Chapter 1. Overview 13
