The DS8886 offers a remote expansion frame option with three remote expansion
frames. This option requires the extended drive cable group C (feature code 1252).
The DS8886 offers a remote expansion frame option with three separate remote
expansion frames. This option requires the extended drive cable groups C, D, and
E (feature codes 1252, 1253, and 1254).
A B C
f2c02371
D E
Up to 20 M
Figure 6. DS8886 with two remote expansion frames
A B C
f2c02372
D E
Up to 20 M
Figure 7. DS8886 with three remote expansion frames
Chapter 1. Overview 15
