The DS8888F uses 8 or 16 Gbps Fibre Channel host adapters that run Fibre
Channel Protocol (FCP), FICON, or (for 8 Gbps adapters only) Fibre Channel
Arbitrated Loop (FC-AL) protocol. The High Performance FICON (HPF) feature is
also supported.
The DS8888F supports three-phase power only.
For more specifications, see the IBM DS8000 series specifications web
site(www.ibm.com/systems/storage/disk/ds8000/specifications.html).
The following tables list the hardware components and maximum capacities that
are supported for the DS8888F (models 988 and 88E), depending on the amount of
memory that is available.
Table 18. Components for the DS8888F (machine type 533x models 988 and 88E)
Processors System memory Processor memory I/O enclosures
Host adapters
(8 or 4 port)
High Performance
Flash Enclosure Gen2
pairs
1, 2, 3
Expansion frames
24-core 1024 GB 512 GB 4 2 - 16 1 - 4 0
48-core 2048 GB 1024 GB 8 2 - 32 1 - 16 0 - 2
1. High Performance Flash Enclosures Gen2 are installed in pairs.
2. A maximum of 8 feature code 1600 are supported in the system. For the remaining 8 High Performance Flash Enclosure Gen2 pair, feature code
1602 should be ordered with feature code 1604.
Table 19. Maximum capacity for the DS8888F (machine type 533x models 988 and 88E)
Processors System memory
Maximum 2.5-in. Flash Tier
0, Flash Tier 1, or Flash Tier
2 drives
Maximum storage capacity
for 2.5-in. Flash Tier 0,
Flash Tier 1, or Flash Tier 2
drives Maximum total drives
24-core 1024 GB 192 1459 TB 192
48-core 2048 GB 768 5837 TB 768
DS8888F base frame (model 988) overview:
The DS8888F includes a base frame (model 988).
The base frame includes the following components:
v High Performance Flash Enclosures Gen2
v Hardware Management Console (HMC), including a keyboard and monitor
v Second HMC (optional)
v Ethernet switches
v Processor nodes (available with POWER8+ processors)
v I/O enclosures
v Direct-current uninterruptible power supplies (DC-UPS)
v Rack power control (RPC) cards
DS8888F expansion frame (model 88E) overview:
The DS8888F supports up to two expansion frames (model 88E) that can be added
to a base frame. A minimum of 2048 GB system memory and a 48-core processor is
required, if an expansion frame is used.
The first expansion frame includes I/O enclosures. You can add up to six High
Performance Flash Enclosure Gen2 pairs to each expansion frame.
20 DS8880 Introduction and Planning Guide
